VIBRAFLEX bridge deck protection course is a multi-ply, semi-rigid asphalt panel composed of a mineral-fortified asphalt core between one liner of asphalt-saturated felt and one layer of fiberglass. One liner is weather-coated and has a polyethylene film facing. It may be used in conjunction with most types of built-up dampproofing and waterproofing membranes, including liquid membranes, sheet membranes of EPDM, butyl, neoprene rubber, polyvinylchloride, as well as built-up systems. It is equally adaptable to concrete, wood, steel, and pre-stressed or precast concrete structures that require waterproofing. VIBRAFLEX is ideal for both new and remedial waterproofing applications.

(click image to enlarge)

Quick Overview

Interested in this item or want more information?
Call Mon. through Fri. 7:00 AM - 5:00 PM CST
Phone: (409) 866-6103
Email: Sales@hbsltd.net

Can't find what you want? Give us a call and we can help you find it.

Details

Large 4' x 8' (1.22 m x 2.44 m) panels can be installed dry, permitting faster, easier installation and savings of 40% to 60% in total installed costs when compared to plank-type products.
Panel size results in fewer joints (90% less), which eliminates infiltration of fines and resulting damage to the waterproofing membrane when compared to plank-type products.
Flexible dual-layer installation complies with current AREMA® Specification in Chapter 9. Eliminates messy hot-mopping and coldbitumen adhesives.
The factory-applied, weather-coated surface permits controlled ballast penetration for a secure seating position which locks the panel to the ballast for effective base stabilization.
Proven by more than three decades of outstanding field performance and service.

Additional Information

Manufacturer: W.R. Meadows
